Barrel Blasting Machines

Barrel blasting machines, also sometimes referred to as tumble blast machines or vibratory finishing machines, are another type of industrial shot blasting machine wholesale at ETSA used for cleaning and surface treatment of parts. They work by tumbling workpieces inside a rotating barrel chamber along with an abrasive media.

Specification of Barrel Blasting Machines

Type

BBM1500

Productivity(t/h)

6

Max. weight of single workpiece (kg)

40

Max. length of single piece(mm)

500

Diameter of drum(mm)

Ø1500

Effective volume(m³)

0.6

Number of blast wheel

1

Blast wheel power(kW)

30

Max. Loading capacity(kg)

1500


*Slide to find out more.

How Does Barrel Blasting Machines Work?

  • Rotating Barrel Chamber: The core component is a cylindrical barrel chamber that rotates on a horizontal axis. This tumbling motion throws the parts against each other and the abrasive media, creating a cleaning and finishing action.

  • Abrasive Media: The chamber is filled with an abrasive media, which can be steel shot, ceramic grit, or even organic media like walnut shells depending on the desired cleaning or finishing effect.

  • Compound (Optional): In some cases, a liquid compound can be added to the blasting media to enhance the cleaning process or achieve a specific surface finish.
