Wire Rod Blast Cleaning Equipment

1

Impeller head

quantity

set

4

1.connection technology with electric motor belt
2.wear resistant parts are wear resistant materials
3.the max impeller head speed 80m/s(adjustable frequency conversion)
4.oil nozzle adding outside impeller head
5.control cage angle labeling can adjust shot angle
6.wear resistant parts hardness HRC≥60-65

The max shot blasting rate

kg/min

4×300=1200

Impeller width

mm

60

power

kW

4×22=88

2

cabinet

quantity

Piece

1

Protection liner plate is wear resistant steel plate

Wearing plate

/

Wearable alloy material

3

curtain separator

quantity

set

1

Separation volume

t/h

80

Separation rate

%

99.9

form

adjustable curtain air separation

power

1.5kw

4

Bucket type lifter

Quantity

set

1

1.Bending composite shell technology
2.Status inspection
3.Prevent belt from reversing
4.The belt is 10 layers of canvas belt with life of about 5000h and the max heat resistance of 150degree

Lifting capacity

t/h

80

Lifting speed

m/s

1.4

power

kW

5.5

5

screw conveyor at the bottom

quantity

Set

1

1.Status inspection
2.Spiral piece is made of 16Mn wear resistant materials

Conveying capacity

t/h

80

Screw diameter

mm

250

power

kW

3

6

Steel shot controller

Quantity

set

4

Rate of flow(max)

kg/min

4×300

Control type

/

ADJ

Control type

/

Air operated

7

Abrasive automatic supplementary device

set

1

When the steel shot abrasive inside sandblasting machine reach the lower limit, supply tank with the external steel shot abrasive can automa tically feed into the body tank so as to reduce the frequent feeding by the operator.

8

power

kW

98
